FC 250
FI SERIES
Steam generator: Production 250/260 Kg./h. Exempt from licensed driver, exempted. Built with the water pipe method connected with a lower collector for easily inspectable sludge deposition.
TECHNICAL DATA
- Heated Area: 6.5 sqm
- Operating pressure: 5 bar
- Steam Production: 250/260 k./h.
- Weight: 720 kg
DIMENSIONS AND WEIGHT
950 x 1590 x 1350 H1 1820
OPTIONAL
- Automatic unloading
- Automatic ignition
DATA SHEET
Built with highly selected materials, thus offering the maximum guarantee of safety and quality. Heating with gas, diesel and derivatives that make it able to work with any burner. Equipped with centrifugal pump, automatic electrical panel according to EEC standards. Our generator is equipped with a steam superheater which allows to raise the thermal content and eliminate humidity.
Possibility of creating a "uniblock" configuration, ie on a single base, together with the steam generator, burner, softener and condensate recovery tank.
